Lace Dyeing Machine

Our dyeing machine factory in Chine, with a decade of expertise, specializes in innovative, reliable equipment. Advanced manufacturing ensures peak performance. Tailored for bulk or custom orders, we empower clients to hit production targets.The lace dyeing machine, designed for intricate laces and embroideries, guarantees uniform dyeing without compromising texture.

Send Inquiry

Product Description

The lace dyeing machine is specially developed for dyeing fine lace fabrics. It uses high-quality stainless steel materials to ensure the long life and high cleanliness of the equipment. The machine combines gentle dyeing technology with precise temperature control, which is particularly suitable for delicate fabrics such as silk and lace, ensuring that the lace can obtain delicate and colorful dyeing effects.

Our dyeing machine factory is located in China and has a 10-year professional background focusing on the production and innovation of dyeing equipment. We use advanced manufacturing processes to ensure that each dyeing machine has excellent performance and reliability. Whether it is large-scale production or small batch customization, we can provide satisfactory products and services to help customers achieve their production goals.

The lace dyeing machine is a dyeing equipment specially designed for fine lace fabrics. Its uniqueness lies in its ability to process lace materials with complex structures and fine textures, such as lace and embroidery, while ensuring uniform dyeing and maintaining the original texture of the fabric. The equipment adopts dye liquid circulation dyeing technology, and avoids the damage to the lace caused by strong mechanical action through precisely controlled temperature and water flow.

The temperature and dye liquid concentration control system of the high-temperature lace dyeing machine is extremely precise, ensuring uniform penetration of the dye, and even the finest lace details can show bright colors. In addition, the lace dyeing machine also has an intelligent control system that can automatically adjust the dyeing parameters according to the lace material and dyeing requirements, improving production efficiency and the stability of dyeing quality.

Parameter (Specification)

Capacity	Customized
Cylinder inner diameter	Customized
Design pressure	0.44MPa
Design temperature	140℃
Heating rate	20℃～130℃ for about 30 minutes
Heating rate	(saturated vapor pressure is 0.7MPa)
Cooling rate	130℃～80℃ for about 20 minutes
Cooling rate	(cooling water pressure is 0.3MPa)
Liquid ratio	1:4-8

Feature And Application

Employing gentle liquid circulation, it avoids fabric damage. Precision-controlled temperature and water flow ensure dye saturation, even in fine details, for vibrant hues.

Specification

Model	Capacity	Main pump
HSHT-AT	KG	KW
AT-20	5	2.2
AT-40	20	4
AT-45	30	7.5
AT-55	50	11
AT-65	80	11
AT-75	100	11
AT-80	140	15
AT-90	180	15
AT-105	250	18.5
AT-120	300	37
AT-150	540	55
AT-190	1000	90
