A Chinese dyeing machine manufacturer with a decade's expertise, we innovate high-performance equipment, catering to diverse enterprise needs. Our zipper dyeing machine, designed for precision, ensures uniform color via integrated immersion-jet dyeing, combating traditional inconsistencies.
The zipper dyeing machine is specially designed for narrow ribbons and zipper dyeing. It is made of top-grade stainless steel to build a solid and durable machine body to ensure long-term operation in harsh industrial environments. The equipment integrates advanced temperature and pressure control technology to accurately apply dyes to ensure that every detail of the ribbon can be evenly colored. The zipper dyeing machine not only improves production efficiency, but also helps brands highlight their unique charm with excellent dyeing quality.
As one of the top dyeing machine manufacturers in China, we have 10 years of industry experience and focus on the research and development and production of high-performance dyeing equipment. Our product line covers a variety of dyeing machines from basic to high-end to meet the production needs of enterprises of different sizes. We are committed to providing customers with more efficient and environmentally friendly dyeing solutions through technological innovation.
The zipper webbing dyeing machine is an advanced dyeing machine designed for zippers and narrow webbing dyeing. Its unique feature is that it can accurately control the dyeing process to ensure that the complex structure of the zipper webbing can meet the color consistency standard. The webbing dyeing machine uses a dyeing technology that combines circulating immersion dyeing and high-pressure jetting to evenly distribute the dye, avoiding the color difference problem common in traditional dyeing methods.
This high-quality dyeing machine has a built-in automatic control system, including precise temperature and time control, which ensures the stability and reproducibility of the dyeing process and improves product quality. In addition, the zipper dyeing machine has a compact structure and a user-friendly operating interface, which not only saves space, but also simplifies the operation process and reduces production costs.
Capacity |
Customized |
Cylinder inner diameter |
Customized |
Design pressure |
0.44MPa |
Design temperature |
140℃ |
Heating rate |
20℃~130℃for about 30 minutes |
(saturated vapor pressure is 0.7MPa) |
|
Cooling rate |
130℃~80℃for about 20 minutes |
(cooling water pressure is 0.3MPa) |
|
Liquid ratio |
1:4-8 |
Equipped with automated controls for temperature and timing, it stabilizes the dyeing process, enhancing quality and repeatability. Compact and user-friendly, this machine optimizes space, simplifies operations, and curtails costs, embodying efficiency and eco-friendliness. The high-quality dyeing machine has competitive prices.
Model |
Capacity |
Main pump |
HSHT-AT |
KG |
KW |
AT-20 |
5 |
2.2 |
AT-40 |
20 |
4 |
AT-45 |
30 |
7.5 |
AT-55 |
50 |
11 |
AT-65 |
80 |
11 |
AT-75 |
100 |
11 |
AT-80 |
140 |
15 |
AT-90 |
180 |
15 |
AT-105 |
250 |
18.5 |
AT-120 |
300 |
37 |
AT-150 |
540 |
55 |
AT-190 |
1000 |
90 |
Automatic cycle spraying ensures uniform dyeing.
Compact design effectively saves factory space.
Easy-to-clean structure simplifies daily maintenance process.
CNC system achieves precise temperature and time control.
